1-осевой модуль SINAMICS S120 SINGLE MOTOR MODULE; внутреннее воздушное охлаждение; книжный формат 6SL3120-1TE21-0AD0

Electronics power supply DC 24 V -15 % / +20 %

Current demand, max. 0.75 A

DC-link current Id 1) 11.0 A

Output current:

Rated value IN 9.0 A
Base load current IH 7.7 A
For S6 duty (40%) IS6 12.0 A
Imax 27.0 A

Type rating:

Based on IN 4.8 kW
Based on IH 4.1 kW

Rated pulse frequency 4.00 kHz

Current carrying capacity:

DC link busbars 3) 100A
24 V busbars 4) 20A
