1-осевой модуль SINAMICS C/D тип, 9А; внутреннее воздушное охлаждение; книжный формат 6SL3120-1TE21-8AD0

Основные характеристики

DC link voltage DC 510 … 720 V

Electronics power supply DC 24 V -15 % / +20 %

Current demand, max. 0.75 A

DC-link current Id1) 22.0 A

Output current

Rated value IN 18.0 A

Base load current IH 15.3 A

For S6 duty (40%) IS6 24.0 A
Imax 54.0 A

Type rating 2)

Based on IN 9.7 kW

Based on IH 8.2 kW

Rated pulse frequency 4.00 kHz

Current carrying capacity

DC link busbars 100 A

24 V busbars 4) 20 A

DC link capacitance 220 μF

Output frequency for servo control 5) 650 Hz

Output frequency for V/f control 6) 600 Hz

Output frequency for vector control 7) 300 Hz
